MV4 :: เครื่องควบคุมการแสดงผลบนวิดีโอวอลล์แบบ 4x4 DVI
MV4 :: เครื่องควบคุมการแสดงผลบนวิดีโอวอลล์แบบ 4x4 DVI

MV4 is a video wall and Multi-viewer processor with 4 DVI inputs and 4 DVI outputs. It can be configurated to 2x2, 1x3 video wall or 4x1 multi-viewer.

● Video wall processor function to configured 2x2 or 1x3 video wall.

● Multi-viewer function, each output can configured as a 4x1 Multi-viewer.

● Matrix switcher function, work as a 4x4 switcher.

● Bezel adjustable function to ensure the best play.

● Image overlap function.

● Output scaling function, output resolution adjustable.

● Position and size adjustable.

● Contrast and brightness adjustable.

● User-friendly control software for free use.

ข้อมูลทางเทคนิค

Video Input 4 DVI (Female DB24+5); T.M.D.S. 2.9V/3.3V; 50Ω
Video Output 4 DVI (Female DB24+5); T.M.D.S. 2.9V/3.3V; 50Ω
Bandwidth 340 MHz (10.2 Gbps)
Max Time-delay 5nS (±1nS)
Crosstalk <-50dB@5MHz
DVI/HDMI Standard DVI1.0/HDMI 1.3, supports EDID and DDC, compliant with HDCP
Control Buttons, USB & RS232 (9-pin female D connector), Optional TCP/IP control
Power Supply 100VAC ~ 240VAC, 50/60H;  25W
Temperature -20 ~ +70℃
Humidity 10% ~ 90%
Chassis Dimension W483 x H44 x D235mm
